Introduction Display Button Functions - Standard Keypad
7
• Preset Indicator - An indicator icon will point to the Preset Field to indicate the Status of the Preset when in
that mode, otherwise it will not appear. It will flash when the Preset is set but disabled and will remain solid
when the Preset is enabled.
Display Button Functions - Standard Keypad
• START - Press to begin a fuel dispense transaction. When START is depressed for more than (2) seconds
multiple delivery mode is initiated. When in multiple delivery mode, press START to stop the current dispense
and start the next one.
• FINISH - Press to end a fuel dispense transaction. After transaction is complete, pressing FINISH will clear the
display of the last transaction and return you to the Pre-Dispense state. Press FINISH to toggle between
displaying the last transaction and the Pre-Dispense state. If depressed for more than a second after transaction
completed and last dispense is called, pressing FINISH initiates a Duplicate Ticket.
When multiple products are available and you are in the Select Product step prior to dispensing, pressing
FINISH will exit the dispense state, and return you to the pre-dispense state.
• MODE - Prior to pressing START Button, press MODE to cycle between Volume, Currency, and Setup Modes.
After pressing START Button, press MODE to cycle between Volume, Currency, and Rate Modes.
• PRESET - In Volume Mode, press to initiate presetting the amount of volume to dispense. Used in conjunction
with the NEXT, ‘+’, ‘-’, and ENTER Buttons to set a preset value.
In Currency Mode, press to toggle between price screen and currency preset screen. Used in conjunction with
the NEXT, ‘+’, ‘-’, and ENTER Buttons to select and set a Price or a preset value.
When the View Tank Load feature is enabled, press to view the tank load volume before or during a delivery.
When both View Tank Load and Tank Load features are enabled, press to modify the tank load volume after
refilling the tank.
• NEXT - Press to enter the value fields - task or function. It is used also to move to the next lesser digit or next
letter in an entry to a value field. At the least significant digit it will wrap to the most significant digit.
• ENTER - Press to accept selection of parameter or alphanumeric values, or to return to prior menu selection.
• Plus button which you press to scroll upward through the menu selections, to increment through numeric
characters 0 to 9, alpha characters Z to A, and special characters for each position in a selected display. Note:
throughout this manual, ‘+’ button will also refer to this button.
• Minus button which you press to scroll downward through the menu selections, to move from alpha
characters A to Z, numeric characters 9 to 0, and special characters for each position in a selected display.
Note: throughout this manual, ‘-’ button will also refer to this button.
Display Button Functions - Optional Keypad
• 0 through 9 - Press to enter alpha, numeric, or special character value into an active field. In alpha or numeric
selections, the cursor advances automatically upon selection of the next number or a different character
represented by the same button (negates the requirement for the NEXT button to be depressed for that
purpose).
• CLEAR
In the Preset Field, press to move the cursor forward one character. 
In the Descriptor Field, press to erase the current character and move the cursor back one space. Depressing
this button for 2 seconds erases the entire Descriptor Field.
• ENTER - Press to accept selection of parameter or alphanumeric values, or to return to prior menu selection
(functions the same as the ENTER button on the standard keypad).
