31
C&C Mode
Initiating the C&C Mode
NOTE: To access C&C Mode you must first configure the display head as instructed in the EMR4 Application
Guide (V-R P/N 577014-339).
1. Press MODE button until the indicator at the bottom of the display points to SETUP.
2. The first C&C Mode category, LANGUAGE, displays in the Descriptor Field. Press NEXT to enter Language
Setup, or continue to press the
button to step through the remaining C&C Mode Setup categories. Press
NEXT to enter any category once it displays in the Descriptor Field.
C&C Mode Setup Categories
• Language setup - sets the volume, currency, setup, and printer label descriptions (see page 32).
• Display Syntax setup - sets the punctuation and decimal places for data displayed in the Preset, Register, and
Totalizer Fields (see
page 35).
• Temperature setup - sets optional temperature probe’s units to Fahrenheit or Celsius (see page 36).
• Fuel Source setup - sets the meter ID, meter input signal type, and product descriptions (see page 37).
• Meter Calibration setup - sets the calibration of the meter by product using one of three methods (see page
44).
• Configure I/O setup - enables various inputs/outputs such as Emergency Stop and Remote Start & Stop
output (see
page 47).
• OEM Message setup - lets you enter the start up OEM message (see page 47).
• Delivery Options setup - This option lets you enable or disable price changing within the Delivery State as per
your regulatory requirements. In this setup you also select coefficient (of expansion) or density as the
temperature compensation method for deliveries, enable delivery timeout, enable Tank ID, enable Custom fields,
enable Tank Load and enable E04 encoder error (Gross volume and Temperature on Ticket fields also visible
when temperature probe connected to EMR Head). Also you can enable / disable Gross Preset, Gross
Viewable, Multicalibrate 0.25% Diff and Multiple Delivery (see
page 48).
• Report Formats setup - lets you print or compose formats for the Delivery Ticket and Shift Report (see page
49).
• Restart setup - allows you to reboot while maintaining current setups, or to reboot and reset all setup selections
to factory default settings as well as removing all current transaction records (see
page 52).
• Security Code setup - allows you to enable security code protection to limit access to selected Setup Mode
categories (see
page 53).
Instructions for setting up the C&C Mode setups are shown in the figures that follow. In some cases multiple
figures are used to explain sub-procedures within a C&C Mode category. Once you have entered a C&C Mode
category (pressing NEXT), do not press the
or buttons in that setup if you do not intend to change a value,
because when you press ENTER, the change, even if unintended, will be accepted. If you want to view setup
settings without making changes, press NEXT to move ‘into’ a category’s setup and ENTER to ‘back out’ of the
setup.
