Introduction
This manual describes setup and operating procedures for the EMR4 Electronic Meter Register System. This
manual assumes that the Display Head, Interconnect Box, and printer are installed and connected.
System Features:
• Time/Date stamping of transaction records
• Volume Mode
• Currency Mode
• Rate Mode
• Temperature Compensation with optional Temperature Probe
References to Time and Date, Currency/Pricing, and Temperature Compensation are found throughout this manual
in setup charts and in operating instructions. The EMR will not display any setup steps connected to an option (in
Setup or C&C Modes) if that option is not installed. When using this manual, please ignore any references to an
option if it is not installed.
System Setup
There are two distinct categories of EMR4 setup; Setup Mode which can be accessed at any time by the
equipment operator, and C&C (Configuration and Calibration) Mode which is only to be entered in accordance
with Weights and Measures (W&M) requirements.
SETUP MODE
The Setup Mode can be accessed by the equipment operator to:
• Establish price, tax, and discount codes
• Set the shutoff points for preset flow control relays 1 and 2
• View/print delivery records
• Select a designated printer type
• Set system component addresses
• Set time delays to blank out display
• Enter shift times, tanker reloads, and print out end-of-shift activity reports
• Enter security codes which can be assigned to delivery functions to prevent unauthorized changes
• Provide Passcode login procedure for access to assigned setup categories
• Restore up to the last 50 transaction records from IB NVRAM storage to a replacement Display Head
• Select month, day, year date formats
• Enter system Time and Date
• View component version numbers
• View Tank Load while making deliveries.
