28
4 Mounting
VEGAPULS 69 • Foundation Fieldbus
47251-EN-160815
Fig.23:Rinsingairconnectionwithcompressionange
Fig.24:Rinsingairconnectionwithadapterange
Youcannddetailsontherinsingairconnectioninchapter"Technical
data".
