11.3 Supplementary information Foundation Fieldbus
The following table gives you an overview of the instrument versions and the corresponding device
descriptions, the electrical characteristics of the bus system as well as the applied function blocks.
Revisions Data DD-Revision Rev_01
CFF-File 010101.c
Device Revision 0101.o
0101.sym
C-Revision xx xx 01
Device software revision
> 4.4.0
ITK (Interoperability Test Kit) Number 5.2.0
Electricial Characteristics Physicial Layer Type Low-power signaling, bus-pow-
ered, FISCO I.S.
Input Impedance
> 3000 Ohms between
7.8KHz-39KHz
Unbalanced Capacitance < 250 pF to ground from either
input terminal
Output Amplitude
0.8 V P-P
Electrical Connection 2 Wire
Polarity Insensitive Yes
Max. Current Load
10 mA
Device minimum operating voltage 9 V
Transmitter Function Blocks Resource Block (RB) 1
Transducer Block (TB) 1
Standard Block (AI) 3
Execution Time
30 mS
Advanced Function Blocks Discret Input (DI) Yes
PID Control Yes
Output Splitter (OS) Yes
SignalCharacterizer(SC) Yes
Integrator Yes
Input Selector (IS) Yes
Arithmetic (AR) Yes
Diagnostics Standard Yes
Advanced Yes
Performance No
Function Blocks Instantiable No
