VEGAPULS 69 • Foundation Fieldbus
47251-EN-160815
11 Supplement
11.1 Technical data
Note for approved instruments
The technical data in the respective safety instructions are valid for approved instruments (e.g. with
Exapproval).Thesedatacandierfromthedatalistedherein,forexampleregardingtheprocess
conditions or the voltage supply.
Torques
Max. torques, threaded version
Ʋ G¾ 30 Nm (22.13 lbf ft)
Ʋ G1½ 200 Nm (147.5 lbf ft)
Max. torques, version plastic horn antenna
Ʋ Mounting screws, mounting strap on
sensor housing
4 Nm (2.950 lbf ft)
Ʋ Flangescrews,compressionange
DN 80
5 Nm (3.689 lbf ft)
Ʋ Flangescrews,adapterangeDN100 7 Nm (5.163 lbf ft)
Max. torques, version metal-jacketed lens antenna
Ʋ Terminal screws for swivelling holder 8 Nm (5.9 lbf ft)
Max. torques for NPT cable glands and Conduit tubes
Ʋ Plastic housing 10 Nm (7.376 lbf ft)
Ʋ Aluminium/Stainless steel housing 50 Nm (36.88 lbf ft)
Materials and weights
316L corresponds to 1.4404 or 1.4435
Materials, wetted parts with metal-jacketed lens antenna
Ʋ Processtting 316L, Alloy C22 (2.4602), Alloy 400 (2.4360)
Ʋ Process seal On site
Ʋ Antenna PP, PEEK
Ʋ seal, antenna system FKM (SHS FPM 70C3 GLT), EPDM (COG AP310)
Materials, wetted parts with plastic horn antenna
Ʋ Adapterange PP-GF30 black
Ʋ Seal,adapterange FKM (COG VI500), EPDM (COG AP310)
Ʋ Antenna cone PBT-GF 30
Ʋ Focussing lense PP
Material, wetted parts rinsing air connection
Ʋ Rinsing air connection PP-GFK
Ʋ Seal FKM (COG VI500), EPDM (COG AP310)
Materials, non-wetted parts
Ʋ Compressionange PP-GF30 black
Ʋ Mounting strap 316L
