Velleman Personal Scope HPS50 - General Information; HPS50 Features; Included Accessories

6
HPS50 PersonalScope
TM
Fig 1.0
General
Fig 2.0
Fig 4.0
Features
• ultra fast full auto set up option
• adjustable trigger level
• X and Y position signal shift
• DVM readout
• audio, power calculation (rms and peak)
• dBm, dBV, DC, rms ... measurements
• signal markers for voltage and time
• frequency readout (through markers)
• recorder function (roll mode)
• signal storage (2 memories)
• high-resolution LCD with backlight
• galvanically separated USB output for PC
• data or bitmap download to PC
• different screen modes
• USB PC Connection real-time and screen capture
Included:
• worldwide adaptor (Fig. 1.0)
• USB cable (Fig. 3.0)
• insulated measurement probe x1/x10 (Fig. 4.0)
GENERAL
Fig 3.0
