DSR Key Controls
You can use the following keyboard shortcuts and mouse controls with the DSR Viewer.
Keyboard Shortcuts
Zoom:
Z = Zoom in
Shift+Z = Zoom out
Z Axis Rotation:
Y = Rotate CW
Shift+Y = Rotate CCW
X Shift:
Y Shift:
L = Left
H = Right
U =Up
D = Down
X Axis Rotation:
P = Rotate CW
Shift+P = Rotate CCW
Y Axis Rotation:
R = Rotate CW
Shift+R = Rotate CCW
Aux. Functions:
Ctrl+ (Z,Y,P,R,F,B,L,H,U,D) Direction =
Fine Movement
Alt+ (Z,Y,P,R,F,B,L,H,U,D) Direction =
Very Fine Movement
DSR Mouse Controls
Rotational:
Left Button/Move
Z Shift:
F = Forward
B = Back
Slide:
Right Button/Move
Zoom:
Scroll forward = Zoom In
Scroll backward = Zoom Out
