HDL-64E S3

High Definition LiDAR Sensor

Page 7

Velodyne LiDAR, Inc.

©

2019

63-HDL64ES3 REV K

360°

Spinning

Lidar

Sensor

26.8°

Valid Data Range

0.9 m to 120 m

(3’ to 394

’

)

Uncalibrated Point

Cloud Data Packets

Calibrated Point

Cloud Data as 3D


Digital Sensor

Recorder and

Viewer Software

XML Laser

Calibration File

Figure 2: LiDAR System Overview
