12
0900‑5017‑ETEE REV‑05
ICON FUNCTION
Internal Memory: Displays available internal memory.
USB Drive: Displays available USB memory. Shows when a USB drive is attached.
Attention: Indicates important text.
USB Flash Drive: Indicates a USB flash drive is detected.
Hourglass: Advises the operator to wait while the system shuts down.
Patient name field: Indicates the patient name text entry field.
Clinician name field: Indicates the clinician name text entry field.
Device Name: Indicates the device name text entry field.
Recording options: Indicates settings for video and audio recording.
Video Rotate options: Indicates settings for video rotation.
System Sounds: Indicates settings for system sounds.
Time zone and daylight savings: Indicates settings for the time zone and
daylight savings time.
Security Code options: Indicates settings for system security code.
Video Timestamps: Indicates settings for video timestamps.
Snapshot Timestamps: Indicates settings for snapshot timestamps
Date options: Indicates settings for the system date.
Time Editor: Icon for the time editor.
Charging indicator: Appears when the monitor is connected to the power
adapter.
Auto‑Shutdown: Indicates settings for Auto‑Shutdown.
Pulse rate: Appears when an external pulse oximeter is connected to the monitor
and receiving readings from the patient.
Note Field options: Indicates settings for note fields.
Reset Settings: Indicates option to reset system settings to factory default.
