16. Ds500+ external connections
VERDERFLEX
3
4
IN OUT
Pump 1
3
4
IN OUT
Pump 2
3
4
4-20mA Daisy Chain
Control Current
IN OUT
Pump
Pump Output to PLC
1
4
PLC
0V / Common
Input
+24V DC
2k2 Typ 1k2 Min
1
IN OUT
Pump
5
Switch Control Run/Stop
2
IN OUT
Pump
5
Manual Pulse Dosing
IN OUT
Pump
PLC Controlling Dosing
2
4
PLC
0V / Common
Pulse Out
+24V DC
2k2 Typ 1k2 Min
INITIAL RELEASE
13/10/22
RO
RO
SH
CT
13/10/22
DS500+ EXTERNAL CONNECTIONS
DS500+
N/A
13/10/22 13/10/22
