Installing the Privacy
Shield
To install a privacy shield:
1.
Align the hooks on the privacy shield with the corresponding
slots beside the keypad on the terminal.
2.
Once the hooks are in place, gently push down on the privacy
shield until it snaps into place.
Mounting Plate
This accessory is used to mount P630 to vertical or inclined
surfaces.
Attaching a Mounting
Plate to P630
To attach a mounting plate to P630:
1.
Align the screw holes at the back of the terminal with the
corresponding screws on the mounting plate (this can be
done with or without the stylus holder attached).
2.
Screw the mounting plate in place, keeping the terminal
aligned.
Mounting P630 with
Mounting Plate to a Wall or
Flat Surface
To mount the terminal to a wall or at surface:
1.
Ensure the mounting plate is attached to the terminal.
2.
Attach three M3 screws (not included in the P630 package)
to the desired surface. Make sure that they are aligned with
the slots on top and at the bottom of the mounting plate.
3.
Secure the terminal with the mounting plate in place by
aligning the holes to the M3 screws and then sliding the
entire assembly into place.
4.
Slide the terminal down to secure it to the mounting plate. To
remove the terminal, slide the terminal up and pull it away
from the mounting plate.
