Installation Guide P630
43
© Verifone Inc. All rights reserved.
The Magnetic Stripe Reader (MSR) must be cleaned regularly (daily
to once a week, depending on usage), as dirt accumulation can lead
to MSR reading problems. MSR can be cleaned using commercially
available card reader cleaning cards or using recommended Verifone
cleaning card (PN 02746-02).
Decommissioning/
Removal from Service
The decommissioning procedure applies to P630 series PCI PTS
version 6.x POI-approved devices.
To securely decommission the device:
1.
Prepare your tool --— a #8 Phillips head screwdriver is necessary.
2.
Ensure that the device is disconnected from power and any other
cables.
3.
Turn the device face down, exposing the rear of the device.
4.
Using the Phillips head screwdriver, remove each of the eight
screws. Four of the screws are covered by the rear cable cover. You
must remove the cable cover to access these screws.
One screw is covered by a tamper-evident security label. Push the
screwdriver through this label to access the screw.
5.
Once all the identied screws have been removed, carefully
separate the top housing plastics from the bottom 1mm, then pinch
the top and bottom housing back together ensuring a proper t.
If using a commercially available cleaning card use ONLY an approved MSR
cleaning card made specically for POS MSR card reader devices or
Petroleum MSR card readers.
Failure to use this decommission procedure causes non-compliance to the PCI
PTS POI Modular Security Requirements version 6.0 approval of the device.
