16
© VeriFone, Inc. All rights reserved.
Installation Guide T650T
Device
Features
Familiarize yourself with the features before continuing with the installation
process.
Figure: 2 T650T (Front
Panel)
Front Panel
The front panel offers the following features:
• The T650T device has a colored touch screen display.
• A smart card reader is built into the front of the device to process smart
card-based debit or credit transactions. For directions on how to use a smart
card, see
Using the Smart Card Reader.
• A magnetic card reader is built into the device for performing debit or credit
card transactions. The card can be swiped in either direction. To ensure a
proper read of the magnetic swipe card, insert the magnetic card from the side
of the device as shown in
Figure 14.
• Contactless Reader and EMV have dedicated LEDs (Light Emitting Diodes)
lower to the left of the display for contactless payments. For directions on how
to perform contactless transactions, see
CTLS Transaction.
• A 3.5 mm audio jack to facilitate accessibility for the visually impaired.
Connection
Ports
The device has dedicated input/output connectors: Ethernet, RS-232, USB-A,
USB-C and DC (Direct Current) power.
Connecting
Cables and
Other Devices
To connect required cables and other devices:
