Installation Guide
T650T
To Connect the
Device to the
External PINpad
Insert the USB-A cable to the T650T de
vice and the external PINpad (P400).
Figure: 10
Connecting
to an
External
PINpad
To Connect the
Device to the
USB port
Insert the USB-C cable to the T650T device and USB-A to download.
Figure: 11
Connecting
PC through
USB-C port
Manual Startup
Hold the start button for about
3 seconds until the device displays the startup
screen.
2
1
]Rŋ
]Rŋ
]Rŋ
24
26
