Installation Guide T650T
To Conduct a
Smart Card
Transaction
1 Position the smart card with the contacts facing upward (see illustration
below).
2 Insert the card into the reader slot in a smooth, continuous motion until it sits
firmly.
3 Wait for the application to indicate a completed transaction before removing
the card. Premature card removal invalidates the transaction.
Figure: 13 Inserting a
Smart Card
Using the
Magnetic Card
Reader
Use the magnetic stripe reader to perform credit and debit card transactions.
Using a Smart
Card Reader -
Debit or Credit
Card
Transaction
1 Position the card with the magnetic stripe facing backward.
2 To ensure a proper read of the magnetic swipe card, insert the magnetic card
from the side of the device, as shown in the illustration below.
Figure: 14 Using
Magnetic
Stripe Card
3 Swipe the card through the magnetic card reader.
