18
© VeriFone, Inc. All rights reserved.
Installation Guide T650T
SAM CARD
When you first receive your T650T device, you may need to install one or more
SAM cards, or you may need to replace old cards. You may need to install one or
two Multiple Security Access Module cards or replace an old one.
Removing the
Battery Cover
Remove the battery cover to access the battery as well as the SIM and SAM slots.
1 Turn off the device.
2 Place the device upside down on a soft, clean surface to protect the screen
from scratches.
3 If installed, loosen the retaining screw.
Press and slide the battery cover, away from the magnetic card reader.
Figure: 5 Removing
the Battery
Cover
Installing or
Replacing
SIM/SAM Card
To install or replace SIM/SAM cards:
1 Power off the device.
2 Place the device face down on a soft and clean surface.
3 Remove the cable cover of the unit.
Observe standard precautions in handling electrostatically sensitive devices.
Electrostatic discharge can damage the equipment. Verifone recommends using
a grounded anti-static wrist strap.
Observez les précautions standard lors de la manipulation d’appareils sensibles
aux décharges électrostatiques. Les décharges électrostatiques peuvent
endommager l'équipement. Verifone recommande d'utiliser un bracelet antista-
tique mis à la terre.
Verifone ships variants of the T650T device for different markets. Your unit may
have different options or accessories described in this section.
