2. You may use the wall
mount bracket as a
template for positioning
the Fios Router.
3. Mark the mounting holes,
then remove the wall
mount bracket from the
wall.
4. Drill holes for the screw
anchors.
5. Insert the screw anchors in the holes in the wall, then
insert the screws into the screw anchors and tighten the
screws. Leave screws extended about 0.2 inches from the
wall.
6. Verify the screws are positioned correctly by placing the
wall bracket on the screws. Remove the wall bracket from
the wall.
7. Place the Fios Router on the
wall bracket and slide the
Fios Router forward until it
locks in place.
8. Slide the wall mount bracket
with the attached Fios
Router on the screws, then
slide the bracket down until it
locks in place.
GETTING TO KNOW
YOUR FIOS ROUTER
