Figure 2.2 DSE with Liebert® MCV Condenser and EconoPhase Pumping Unit
Item Description
1
Air-cooled with Liebert® MCV™ Condenser with Econo-Phase™ Pumping Unit—All the features of a standard air-cooled
system, with the added benefit of an economizer mode that can be used when the outdoor temperature is cold enough to
cool the refrigerant enough to suspend use of the compressors.
2 Liebert® DSE™ Thermal Management System
3
Liebert® MCV™ Condenser with EconoPhase Pumping unit and DSE receivers mounted, wired, and piped on a common
heat-rejection skid for ease of job-site deployment.
Table 2.5 DSE Air-cooled with MCV Condenser and EconoPhase Pump Cooling Descriptions
2 Nomenclature and Components 15
