4.4 Placing the Unit on a Floor Stand
Refer to the floor-stand installation sheet, located inside the floor-stand package. Lower the unit onto the
floor stand. Refer to Figure 4.7 below. Be sure to align the welded tabs on top of the floor stand with the
inside of the unit frame base.
NOTE: The floor stand for the units equipped with EC fans is not symmetrical. Its orientation to the
unit is critical for lowering the EC fans. Unless the floor stand is installed in the correct position, the
fans will not lower into the floor stand.
Figure 4.7 Welded tabs on floor stand
Item Description
1 Front of unit
