Document Number Title
Electrical Connections
DPN004387 Electrical Field Connections, Upflow & Downflow, DA050, DA080, and DA085 Models
DPN004388 Electrical Field Connections, Downflow Models, DA125, DA150, and DA165
DPN003284
CANbus cable connections between indoor unit, 1 Liebert® MCcondenser and optional
Liebert® EconoPhase pump
DPN002361
CANbus cable connections between indoor unit, 2 Liebert® MCcondensers and optional
Liebert® EconoPhase pump
Unit-to-Unit Networking
DPN004351 Liebert® iCOM Unit-to-unit Network Connections
Disassembly Dimensions - Downflow Units
DPN003532 Disassembly, DA050
DPN003140 Disassembly, DA080 and DA085
DPN003178 Disassembly, DA125, DA150 and DA165
Disassembly Dimensions - Upflow Units
DPN003166 Disassembly, DA080U and DA085U
Table C.1 Submittal-drawings Contents (continued)
