SPECIFICATIONS44
MODEL EDGE-750IMT EDGE-1000IMT EDGE-1500IMT
Power Rating @ 230V 750VA / 675W / 3.3A 1000VA / 900W / 4.4A 1500VA / 1350W / 6.7A
Output
Output Voltages (on
battery)
200 / 208 / 220 / 230 / 240 VAC
(230 VAC is factory default)
Output Frequency (on
battery)
Autodetect 50/60 Hz ±1%
Output Receptacles -
controllable
(3) IEC 320 C13
Output Receptacles -
controllable
(2) IEC 320 C13 (3) IEC 320 C13
Transfer Time Adjustable with Input Waveform Sensitivity setting. See page xx for details.
Output Waveform (on
Battery)
Pure Sinewave
Output Overload Operation
101% - alarm warning
106% - alarm warning and shutdown after 60 seconds
126% - alarm warning and shutdown after 50 seconds
151% - alarm warning and shutdown after 2 seconds
201% - alarm warning and immediate shutdown
Protection Electronic (over current, short circuit w/ latching shutdown)
AC-mode Eiciency 98% or greater for 200/208/220/230/240 VAC
Buck- Boost1- and Boost2-
mode
95% or greater for
200/208/220/230/240 VAC
96% or greater for 200/208/220/230/240 VAC
Recharge Time 4 hours to recover 90%
Internal Battery
Part Number EDGE-750IMTBATKIT EDGE-1000IMTBATKIT EDGE-1500IMTBATKIT
Protection Electronic (overcurrent, short circuit with latching shutdown)
Type Valve-regulated lead-acid (VRLA) in compliance with UL 1989
Quantity x Voltage x Ah 2 x 12V x 9Ah 2 x 12V x 10Ah 4 x 12V x 9Ah
Battery Manufacturer and
model No.
CSB HR1234W CSB UPS12580 CSB HR1234W
