Vertiv | Liebert® EDGE | Installer/User Guide 45
Table 5-3 Specifications, EDGE-1500IRT2UXL, EDGE-2200IRT2UXL,EDGE-3000IRT2UXL and EDGE-3000IRT3UXL
MODEL EDGE-1500IRT2UXL EDGE-2200IRT2UXL EDGE-3000IRT2UXL EDGE-3000IRT3UXL
Power Rating @ 230V
1500VA / 1350W
/ 6.7
2200VA / 1980W
/ 9.8A
3000VA / 2700W / 13.3A
Dimensions, D×W×H, in. (mm)
Unit Dimensions,
W x D x H, mm
438 x 510 x 88 438 x 630 x 88 438 x 485 x 132
Shipping Dimensions,
W x D x H, mm
565 x 700 x 240 600 x 800 x 240 550 x 670 x 282
Weight, lb.(kg)
Unit Weight, kg 21.5 26.7 33.8 36.4
Shipping Weight, kg 29.6 34.9 41.6 42.1
Input
Voltage Input Range (with
battery operation)
0 to 300 VAC
Voltage Input Range
(without battery operation)
144 to 290 VAC
Input Voltage Measurement
Tolerance
±5%
Nominal Voltage Setting 200 / 208 / 220 / 230 / 240 VAC
High Line Buck to Battery 241 / 251 / 266 / 278 / 290 VAC
High Line Battery to Buck 235 / 245 / 260 / 272 / 284 VAC
High Line Normal to Buck 220 / 229 / 242 / 253 / 264 VAC
High Line Buck to Normal 215 / 224 / 237 / 248 / 259 VAC
Low Line Boost1 to Normal 185 / 192 / 203 / 212 / 221 VAC
Low Line Normal to Boost1 180 / 187 / 198 / 207 / 216 VAC
Low Line Boost2 to Boost1 160 / 166 / 176 / 183 / 191 VAC
Low Line Boost1 to Boost2 155 / 161 / 171 / 178 / 186 VAC
Low Line Battery to Boost2 155 / 161 / 171 / 178 / 186 VAC
Low Line Boost2 to Battery 144 / 150 / 158 / 166 / 173 VAC
Frequency Input Range
45 to 65 Hz
Autodetect 50 / 60 Hz
Battery to Normal comeback at 50Hz: 47 to 53Hz
Battery to Normal comeback at 60Hz: 57 to 63Hz
Internal Rear-panel Input
Breaker Rating
10 A 16 A
Input Surge Protection EN61000-4-5; Line to Line: Level 2; Line to Earth: Level 3
Input Power Receptacle IEC 320 C14 IEC 320 C20
Output
Output Voltages (on
battery)
200 / 208 / 220 / 230 / 240 VAC
(230 VAC is factory default)
