SPECIFICATIONS46
MODEL EDGE-1500IRT2UXL EDGE-2200IRT2UXL EDGE-3000IRT2UXL EDGE-3000IRT3UXL
Power Rating @ 230V
1500VA / 1350W
/ 6.7
2200VA / 1980W
/ 9.8A
3000VA / 2700W / 13.3A
Output
Output Frequency (on
battery)
Autodetect 50/60 Hz ±1%
Output Receptacles -
controllable
(3) IEC 320 C13
(3) IEC 320 C13
(1) IEC 320 C19
(6) IEC 320 C13
(1) IEC 320 C19
Output Receptacles -
controllable
(3) IEC 320 C13
Transfer Time Adjustable with Input Waveform Sensitivity setting. See page xx for details.
Output Waveform (on
Battery)
Pure Sinewave
Output Overload Operation
101% - alarm warning
106% - alarm warning and shutdown after 60 seconds
126% - alarm warning and shutdown after 50 seconds
151% - alarm warning and shutdown after 2 seconds
201% - alarm warning and immediate shutdown
Protection Electronic (over current, short circuit w/ latching shutdown)
AC-mode Eiciency 98% or greater for 200/208/220/230/240 VAC
Buck- Boost1- and Boost2-
mode
96% or greater for 200/208/220/230/240 VAC
Recharge Time 4 hours to recover 90%
Internal Battery
Part Number
EDGE-
1500IRT2UBATKIT
EDGE-
2200IRT2UBATKIT
EDGE-
3000IRT2UBATKIT
EDGE-
3000IRT3UBATKIT
Protection Electronic (overcurrent, short circuit with latching shutdown)
Type Valve-regulated lead-acid (VRLA) in compliance with UL 1989
Quantity x Voltage x Ah 4 x 12V x 9Ah 6 x 12V x 7Ah 6 x 12V x 10Ah
External Battery Cabinets
Model Number GXT5-EBC48VRT2U GXT5-EBC72VRT2U
Type Valve-regulated lead-acid (VRLA) in compliance with UL 1989
Protection Circuit breaker
Battery Manufacturer and
model No.
CSB HR1234W CSB GP1272 CSB UPS12580
Quantity x Voltage x Ah 4 x 12V x 9Ah 6 x 12V x 9Ah
Dimensions, W x D x H, mm 430 x 497 × 85 430 x 602 x 85
Shipping dimensions, W x D
x H, mm
570 x 617 x 262
Unit weights, kg 28.5 39
Dimensions, W x D x H, mm 41.5 50
