Operation and Display Panel46
4.2.2. Main Menu
To access the main menu, press Enter while at the ow screen. Table 4-3 below, describes the menu options, and
Figure 4-4 below, describes the display.
Use the arrow buttons to select the sub-menu options, and press Enter to open the sub menu. Press ESC to
return to the ow.
Table 4-3 Menu Options
SUB
MENU
DESCRIPTION
Status Voltage, current, frequency, and parameters for UPS components, see Status Screen on the next page.
Settings Display and system parameter settings, see Settings Submenu on page 47.
Control UPS controls, see Control Screen on page 48.
Log Current alarms and event history, see Log Screen on page 48.
About Product and network information, see About Screen on page 52.
Maintenance Service-only, service-password protected page for use only by Vertiv service representatives.
Figure 4-4 Main Menu
ITEM DESCRIPTION
1 ECO-mode indicator
2 Ambient temperature and humidity. Only displays when sensors are connected.
3 Date and time

Vertiv LIEBERT GXT5 Series Specifications

General

Model	LIEBERT GXT5 Series
Product Type	UPS
Topology	Double Conversion Online
Display	LCD
Form Factor	Tower, Rackmount
Output Voltage	200/208/220/230/240 VAC
Output Frequency	50/60Hz ±0.1Hz (battery mode)
Typical Backup Time	Varies by model and load
Communication Ports	USB, RS-232
Operating Temperature	0°C to 40°C (32°F to 104°F)
Relative Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Certifications	UL, cUL, CE, RoHS
Battery Type	Valve Regulated Lead Acid (VRLA)
