Vertiv Netsure User Manual

NetSure
™
Control Unit (NCU)
User Manual, UM1M830BNA
Spec. No: 1M830BNA, 1M830DNA Code: UM1M830BNA
Model No: M830B, M830D Revision M, May 12, 2017
[106]
Individual Converter Settings Page
In Figure 37, hover the mouse pointer on an individual converter icon , this icon changes to . Click to go to the individual
converter settings page. Click to go back to the individual converter status page.
Figure 39. Selecting an Individual Converter Settings Page
Figure 40. Individual Converter Settings Page
NOTE: Settings that appear "grayed out" can only be made when the controller is in the "manual control" state. If the controller is set for
"automatic" control, change the “Auto/Manual State” setting first to the “Manual” setting.
 DC On/Off Control: Temporarily turns the converter’s DC output on or off when the controller is in Manual mode. Setting
returns to original when controller is returned to the Auto mode.
 Over Voltage Reset: Temporarily sets the converter’s over voltage reset feature when the controller is in Manual mode. Setting
returns to original when controller is returned to the Auto mode.
 LED Control: Temporarily sets whether or not a converter's local power indicator blinks when the controller is communicating
with the converter when the controller is in Manual mode. Setting returns to original when controller is returned to the Auto
mode.
 Converter ID: Sets the converter’s identification number.

Vertiv Netsure Specifications

General

Brand	Vertiv
Series	Netsure
Humidity Range	5% to 95% non-condensing
Cooling Method	Forced air
Communication Interface	Ethernet
Protection Features	Overvoltage, overcurrent, short circuit, overtemperature
