NetSure
™
Control Unit (NCU)
User Manual, UM1M830BNA
Spec. No: 1M830BNA, 1M830DNA Code: UM1M830BNA
Model No: M830B, M830D Revision M, May 12, 2017
Unimplemented Parameters
The following two parameters do not apply to this application. A <null> value is inserted for them.
<locn> - location of alarm condition
<dirn> - direction of alarm condition
<tmper>
This is the accumulation time period for PM parameters. In this application, it represents the length of time the alarm
condition has been active. The format for this parameter is “VAL-UN”, where valid values for VAL (value) and UN (units) are
given below.
VAL UNIT
1 DAY (days) - used if alarm is active longer than 24 hours.
1 to 24 HR (hours)
1 to 1440 MIN (minutes) - used if alarm is active less than 24 hours.
<conddescr>
This parameter is a text message which provides a detailed description of the alarm, event, or condition. It is an ASCII
string enclosed within a pair of escaped quotes(\”). It may also be used to describe any action to be taken as a result of the
condition.
Unimplemented Parameters
NOTE: The following parameters will either not be implemented or do not apply to this application. A <null> value is returned for these
parameters.
<aiddet> - supplementary equipment identification
<obsdbhvr> - observed behavior that resulted in reported trouble
<exptdbhvr> - expected behavior that was deviated from
<dgntype> - diagnostic routine used to isolate trouble
<tblistl> - provides isolation information
