31 - 32. Engine temperature sensor - fuel injec-
tor - Remove the helmet compartment to reach it.
33. H.V. coil - Remove the helmet compartment
and undo the two screws indicated to reach it.
Ground points
On the vehicle there is a chassis ground point,
marked with letter "A", on the right side of the bat-
tery compartment.
Electrical system Vespa LX 125 - 150 i.e.
ELE SYS - 56

Vespa LX Series Specifications

General

Displacement	124 cc
Cooling System	Air-cooled
Front Tire	110/70 - 11"
Rear Tire	120/70 - 10"
Seat Height	785 mm
Kerb Weight	114 kg
Wheelbase	1, 280 mm
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Engine Type	Single-cylinder, 4-stroke
Fuel System	Carburetor
Max Torque	10.4 Nm @ 6, 000 rpm
Transmission	Automatic
Front Suspension	Single-sided trailing arm with hydraulic shock absorber
Rear Suspension	Hydraulic shock absorber
Front Brake	200mm disc brake
Rear Brake	110mm drum brake
