Vespa LX Series - Back Side

Back side
1. To the front part
2. To the magneto flywheel
3. To HV coil
4. To the rear lighting devices
5. Chassis ground
6. Start-up remote control switch
7. Fuel level transmitter
8. Battery
9. Diagnostic socket
10.Generator connector
11.Pick-up connector
Electrical system Vespa LX 125 - 150 i.e.
ELE SYS - 58
