Remove plugs (1 a) and t camshaft timing tools (1b) on the cam-
shaft housing.
Check that the tools marked “A” are correctly tted in the seats
on the camshaft.
Remove the timing tool, (templates) camshaft side, and tighten
the plug.
Fit a new upper cylinder head basket in position.
Position the camshaft housing and secure it by tightening the
bolts to the recommended torque.
Camshaft housing
Bolt M8 (daNm) 2.3 ÷ 2.8 (cylinder head side
Loosen the bolt xing the exhaust side timing belt toothed drive
pulley.
Undo the bolt xing the crankcase front cover shown in the dia-
gram.
Temporarily t the toothed timing drive belt on the toothed drive
pulley.
