Operation
39
Stubble height
The stubble height is adjusted in the following way:
> Lower the cutting unit to the ground.
> Set the stubble height by adjusting the top link.
• Making the top link shorter reduces the stubble height
• Making the top link longer increases the stubble height.
The stubble height can be combined with fitting high skids* which can
be used to set the stubble height as follows:
* Extra equipment.
»Optional equipment« page 85
Ground pressure
Checking the ground pressure of the machine:
»Adjusting the ground pressure« page 31
T
IP
!
The recommended weight should be approx. 50-60 kg (110-130 lb).
Stubble height Note
20 - 50 mm
(
3
/4” - 2”)
No skids fitted
25 - 70 mm
(1” - 2
3
/4”)
20 mm (
3
/
4
”) skids* fitted
50 - 100 mm
(2” - 4”)
40 mm (1
9
/16”) skids* fitted
100 mm (4”)
or more
80 mm (3”) skids* fitted
