Operation
41
In the working position in the field, there must be 15-30 mm (
5
/8”- 1
3
/
16”) clearance between the lock catch and the stop so that the
cutterbar can “float” and follow the ground.
 »Adjusting the working height« page 29
15 - 30 mm (
5
/8”-1
3
/16”)
Lock catch
Stop
