Maintenance
69
V-belt
Safety concerning maintenance work on the transmission
When working on the transmission the tractor must be stopped and
secured.
This prevents the machine from suddenly starting to rotate.
If the tractor and the PTO shaft have not been connected in
accordance the instructions, serious accidents causing damage to
limbs can occur.
When working on the transmission:
• The tractor engine must be stopped.
• The ignition key must be removed.
• The PTO shaft must be disconnected.
• The tractor hydraulic system must be disconnected.
• The hand brake must be activated.
After 10 working hours
Thereafter, every 40
hours of use
»Maintenance intervals« page 53
The V belt transmission must be regularly checked.
The v-belt transmission is checked in the following way:
> Check that the distance between the nut and the edge of the guard
is as shown.
