80
Maintenance
> Fit the knife and bolt on the new cutting disc.
> Tighten the bolt to the given torque.
> Apply Loctite 242 or a similar product to all bolts.
> Fit the cutting disc on the cutterbar.
> Tighten the bolts to the given torque.
> Close the guards around the machine's cutterbar.
> Fit the pin.
Bolt
95 Nm +/- 5
(70 ft. lbs. +/- 4)
Loctite 242
Bolt
80 Nm +/- 5
(59 ft. lbs. +/- 4)
