84
Maintenance
> Remove the old V-belts.
> Fit the new V-belts.
> Tighten the nut until the distance between the nut and the edge of
the guard is as shown.
> Fasten counter-nut.
> Fit the guard.
NB The V-belts should be checked after the first 10 working hours.
 »V-belt« page 69
V-belt
0 mm (0”)
