Maintenance
104
Open the mechanical safety valve.
Adjust the tractor's lift arms to the height shown.
It is important that the PTO shaft between the tractor and machines is
horizontal. If the PTO shaft is not horizontal, the universal joint in the
axle may be damaged.
Lock the lift arms with a chain or solid bar between the lift arm and
highest point.
530 - 600 mm (21’’ - 23 ½’’)
