Maintenance
103
Remove the oilplug to check the oil level.
Fill up with the new oil until the oil level is as shown.
Check the oil level using a measuring instrument.
→ »Lubricants« page 134
Fit the oilplug and tighten it fully.
Pull out and release the lock for the guard.
Close the machine's front guard.
Model Litre
(approx.)
Pint (US)
(approx.)
Pint (imp)
(approx.)
532 4.1 8.6 7.2
540 5.1 10.8 9.0
