Vicon Extra 532 - Swivel Hitch Oil Fill (Upper)

Maintenance
108
 Remove oilplug 1 and 2.
 Fill the new oil through the hole for oilplug 1.
• The correct oil level is reached when the oil reaches the edge of
the hole for oilplug 2.
 Fit oilplugs 1 and 2 and tighten them.
→ »Lubricants« page 134
 Fit the guard.
Oilplug 2
Oilplug 1
