Maintenance
109
The lower part of the swivel hitch
→ »Maintenance intervals« page 61
Oil amount when changing oil:
The oil is changed as follows:
Use a suitable tool to remove oilplug 6.
Let the oil flow into a suitable container.
Allow the last of the oil to drip out of the transmission for approx.
10 - 15 minutes.
Fit oilplug 6 and tighten it.
Remove oilplugs 4 and 5.
Fill the new oil through the hole for oilplug 4.
The correct oil level is reached when the oil reaches the edge of
the hole for oilplug 5.
Fit oilplugs 4 and 5 and tighten them.
→ »Lubricants« page 134
Litre
(approx.)
Pints (US)
(approx.)
Pints (Imp.)
(Approx.)
1.8 3.8 3.2
Oilplug 5
Oilplug 4
Oilplug 6
