Preparation
26
The swivel gear's rpm can also be checked by observing the gear's
pivot joint.
Check the swivel gear in the following way:
Observe the gear's profile in the middle of the swivel gear.
• If the swivel gear's profile on the lower part of the swivel gear is
wide, the machine should be run at a rotational speed of 1000 rpm.
• If the swivel gear's profile on the lower part of the swivel gear is
narrow, the machine should be run at a rotational speed of 540
rpm.
RPM on the PTO outlet
540 RPM
From the factory the machine is adapted to tractors that run at 540
RPM on the PTO.
Wide profile
Narrow profile
The rotational speed of the tractor's
PTO outlet = 1000 rpm.
The rotational speed of the tractor's
PTO outlet = 540 rpm.
