Vicon Extra 532 - 1000 RPM

Preparation
27
1000 RPM
If the machine is to be fitted to a tractor's PTO shaft running at 1000
RPM, the following procedure must be followed:
 Remove the PTO shaft.
 Remove the bolts shown on both sides of the transmission.
 Remove the bracket.
 Remove the guard.
 Force the corners of the lock plate away from the bolt heads.
Bolt
Bracket
