Assembly - attachment
35
Lock the lift arms with a chain or solid bar between the lift arms and
highest point.
* Optional equipment.
→ »Extra equipment« page 125
Attach the PTO shaft to the tractor.
When checking and shortening the PTO shaft, refer to the manufac-
turer's instructions, delivered with the PTO shaft.
It is important that the PTO shaft between the tractor and machines is
horizontal. If the PTO shaft is not horizontal, the universal joint in the
axle may be damaged.
