67009600-EN - Edition 2015 - Rev. 1.0
9
VX2300 Digital System - “2 Wire” Audio/Video Door Entry System
VX2300 Digital System - Installation handbook
UNIT SPECIFICATION
Housing/Mounting: One 4000 Series Module / 4000 Series Modular System
Push Buttons: Yes, from 0 to 2 call buttons according to the model
Programming: Yes, carried out by the 8 way dip-switch located on the rear of the module
Controls: Microphone and Loudspeaker volume trimmers plus balance trimmer
Front plate nishes: Mirror stainless steel (standard), Anodized Aluminium (add /a after the product code) or High Brass (add /HB)
Power Supply: Supplied by the BUS line
Power consumption: Stand-by: 28mA
Operating: 38mA
Working Temperature: -10 +50 °C
Art.4303N Speaker unit module with built-in functional to digital interface
