VX2300 Digital System - “2 Wire” Audio/Video Door Entry System
VX2300 Digital System - Installation handbook
Index
Introduction
The VX2300 VIDEX Digital system is a complete video door entry system based on a two wire BUS.
The main features are the following:
• 2 wire bus (not polarity conscious);
• Up to 200 meters VIDEX specic cable or 100 meters using standard telephone cable;
• Up to 8 video outdoor stations (b&w or colour camera);
• Digital or functional front panels;
• Digital front panels with speech playback and PC programming facilities;
• Up to 100 extensions (maximum 100 units in total on the system, either intercoms, videointercoms or peripherals);
• Up to 4 devices on each extension (maintaining the maximum 100 units in total on the system);
• Intercommunication between devices on the same extension or between devices with dierent extension;
• Local door bell facility;
• Active oor divider (With oor isolation);
• Availability of relay modules for extra services directly connected to the bus;
• Electric lock powered by the outdoor station.
Introduction .......................................................................................................................................................................................2
Outdoor stations
Art.4302N Digital call panel .................................................................................................................................................................................................... 3
Art.4303N Speaker unit module with built-in functional to digital interface ....................................................................................................... 6
Art.4330N Camera module specic for VX2300 Digital System ...............................................................................................................................10
4000 Series Surface and ush mounting door station installation .........................................................................................................................11
Intercoms
Art.3181 Digital intercom for VX2300 2 Wire System .......................................................................................................................................... 13
Art.3183 Digital intercom for VX2300 2 Wire System .......................................................................................................................................... 16
Art.5188 Hands free intercom .............................................................................................................................................................................................18
5000 Series Hands free intercom wall mounting instructions ..................................................................................................................................22
Videointercoms
Art.3686 Digital videophone ...............................................................................................................................................................................................23
3600 Series Videophone wall mounting instructions ..................................................................................................................................................27
Art.SL5488N Slim hands free videomonitor ..................................................................................................................................................................28
5000 Series Videomonitor wall mounting instructions ...............................................................................................................................................32
Art.6286 3.5" colour display videophone ........................................................................................................................................................................33
6200 Series Videophone wall mounting instructions ..................................................................................................................................................37
Art.6388 3.5" hands free colour display digital videophone .................................................................................................................................... 38
6300 Series Wall mounting instructions ............................................................................................................................................................................ 42
Art.6488 4.3" hands free colour display digital videophone .................................................................................................................................... 43
6400 Series Wall mounting instructions ............................................................................................................................................................................ 47
Art.KRV88-KRV86 3.5” hands free videomonitor for VX2300 digital system ...............................................................................................48
Kristallo Series 3.5" ush and surface videomonitor wall mounting instructions ............................................................................................54
Art.KRV782 7” Hands free videomonitor for VX2300 digital system ......................................................................................................................56
Kristallo Series 7" ush and surface videomonitor wall mounting instructions ................................................................................................ 60
Accessories
Art.317N Active/passive four way distribution box ......................................................................................................................................................62
Art.318 Two way passive distribution box .............................................................................................................................................................. 63
Art.2315 BUS booster and video signal amplier ................................................................................................................................................64
Art.2301N Entrances exchanger for VX2300 digital systems ....................................................................................................................................65
Art.2306N Block exchanger .........................................................................................................................................................................................66
Art.2305 Extension Relay for VX2300 digital systems ......................................................................................................................................... 68
Art.2380 Interface “2 Wire” to “4+1” audio system ................................................................................................................................................69
Art.2321-2321/P Power supplies for VX2300 ........................................................................................................................................................72
Art.2322 Power supply converter from BUS line to 12 Vdc ........................................................................................................................................73
General directions for installation ................................................................................................................................................ 74
Addresses table for dip-switch banks ........................................................................................................................................... 76
Installation diagrams ..................................................................................................................................................................... 80
