14
Removing the front panel
Fig. 4
1. Unlock the front panel on the underside (push in),
using a screwdriver or similar tool.
2. Swivel the front panel forwards slightly and lift
away upwards.
Note
Do not remove protective caps from connections
on the heating water side and from the gas con-
nection until you are about to commence installa-
tion.
Mounting the boiler on the pre-plumbing jig or mounting frame
Note
Various installation components can be found in a sep-
arate pack. Keep the installation components safe, as
they will be required for later installation.
Installation sequence
Mounting the boiler and making connections
5593201
Installation
