Viessmann B2HF - Fitting the Programming Unit Mounting Bracket on the Top of the Boiler

18
Fitting the programming unit mounting bracket on the top of the boiler
In the delivered condition, the programming unit is
located on the underside of the boiler. If required for
ease of operation, the programming unit can be loca-
ted on the top of the boiler. To do so, reposition the
bracket at the top.
2x
2.
3.
8.
180°
4.
5.
6.
!
7.
1.
Fig. 7
Installation sequence
Mounting the boiler and making connections (cont.)
5593201
Installation
