Viking DEDO130SS - Outer Door Panel Removal; Outer Door Glass Removal

22
Outer Door Panel Removal
CAUTION: Use care when handling the door
assembly. Do not lift or carry the door by the
handle.
Condition Requirements:
Door Assembly Removed
1. Place the door handle side down on a
protected surface.
2. Remove seven screws that attach the outer
door panel to the door liner.
3. Turn the door over and lift the outer door
panel from the door liner.
4. Reverse procedure for installation.
Outer Door Glass Removal
Condition Requirements:
Outer Door Panel Removed
1. Remove four screws that attach the outer
door glass assembly to the heat barrier.
2. Remove the outer door glass from the heat
barrier.
3. Reverse procedure for installation.
