Troubleshooting Guide
Problem Probable Cause Correction
No bake, no broil, no
oven lights, no power
to timer L1-L2.
House breaker or fuse open.
Defective oven wiring (shorted,
open, or burned).
Reset breaker or replace fuse.
Repair or replace defective wiring.
No bake, no broil, no
oven lights, timer
display on.
Open thermal cut-out.
Open power board.
Defective oven wiring (shorted,
open, or burned).
Replace TCO. (Check operation of
blower motor.)
Replace power board.
Repair or replace defective wiring.
No bake, timer
display on, oven
lights operate.
Open bake element.
Open selector.
Open thermostat.
Open relay K10 or K11.
Open power board.
Defective oven wiring (shorted,
open, or burned).
Replace bake element.
Replace selector.
Replace thermostat.
Replace power board.
Replace power board.
Repair or replace defective wiring.
No broil, timer
display on, oven
lights operate.
Open broil element.
Open selector.
Open thermostat.
Open relay K12 or K13.
Open power board.
Defective oven wiring (shorted,
open, or burned).
Replace broil element.
Replace selector.
Replace thermostat.
Replace power board.
Replace power board.
Repair or replace defective wiring.
No convection bake,
timer display on,
oven lights operate.
Open bake element.
Open broil element.
Open convection fan motor.
Open selector.
Open thermostat.
Open relay K10, K11, K12, K13,
K5, or K7.
Open power board.
Defective oven wiring (shorted,
open, or burned).
Replace bake element.
Replace broil element.
Replace convection fan motor.
Replace selector.
Replace thermostat.
Replace power board.
Replace power board.
Repair or replace defective wiring.
No convection roast,
timer display on,
oven lights operate.
Open broil element.
Open convection element.
Open convection fan motor.
Open selector.
Open thermostat
Open relay K12, K13, K14, K5,
K6, or K7.
Open power board.
Defective oven wiring (shorted,
open, or burned).
Replace broil element.
Replace convection element.
Replace convection fan motor.
Replace selector.
Replace thermostat.
Replace power board.
Replace power board.
Repair or replace defective wiring.
