Viking DEDO130SS - Page 46

46
Component Operating Voltage
(approximate)
Resistance
(approximate)
Test Location
Oven Light
Transformer –
primary
240 VAC 28 Ohms L2 – P12 yellow
Oven Light
Transformer –
secondary
12 VAC 0.1 Ohms Transformer – 2 black
wires
Analog Timer 240 VAC 0.57 Ohms Timer L1 – L2 (N)
Digital Timer 240 VAC 1.2 Ohms Timer L1 – L2 (N)
RTD (Resistive Thermal Device)
Temperature (°F)
Resistance
(approximate)
50 1038
75 1090
100 1143
200 1350
300 1553
350 1654
400 1754
450 1852
500 1950
550 2047
600 2153
650 2238
700 2332
750 2425
800 2518
850 2609
900 2700
