Bake Element Removal
WARNING: Disconnect power to oven
before servicing. Follow lockout/tagout
procedures.
Condition Requirements:
Door Assembly Removed
1. Remove the two screws that hold the bake
element access panel to the oven frame.
2. Remove the insulation from the recess.
3. Remove the two screws that attach the
bake element to the element shelf.
4. Slide the bake element partially out, mark
and disconnect the four wires from the
bake element.
5. Remove the bake element from the oven
6. Reverse procedure for installation.
Catalyst Removal
Condition Requirements:
Convection Baffle Removed
1. Remove the two screws that hold the oven
catalyst to the top, left, rear corner of the
oven liner.
2. Pull down the oven catalyst.
3. Reverse procedure for installation.
